Description
Maximum load capacity 5000 kg
Lift height 17.4 m
Maximum reach 13.5m
Lift height at max. load capacity 9.2m
Reach at max. load capacity 3m
Load capacity at max. lift height 2500m
Load capacity at max. reach 550 kg
Boom side-shift +/- 445 mm
Boom section 4
Engine Perkins 904J
Range/Cylinders 3600/4
Anti-pollution technology
Stage V - SCR + DPF + DOC
Reversible Fan
Maximum speed 40 km/)
Hydrostatic transmission
Joystick autoaccelerante
Automatic parking brake
Auxiliary hydraulic service on boom
Controls Joystick elettronico
Tac-lock
Three steering way
Standard tyres 400/80-24
OPT tyres 440/80-24; 445/65-22,5”
Hydraulically controlled stabilizers
A - Lenght 6190
C - Wheelbase 3060
F - Ground clearence 485
H - Width 2480
M - Cabin width 1010
P - Height 2535
R - Turning radius at wheels 4265
S - Turning radius at forks 5611
Ready to work
